Starfoil 1050

Max.sheet size: 1050X750 mm
Min. sheet size: 450X370 mm
Stock range: 150~500 g/m²
Max. diecutting size: 1040X730 mm
Chase inner size: 1120X760 mm
Cutting knife height: 23.8 mm
Standard distance between platens: 32 mm
Min. gripper margin: 8 mm
Feed pile height: 1100 mm
Delivery pile height: 850 mm
Max. stamping size: 1020X700 mm
Impression strength: 2.5X106 N
Max. diecutting speed: 5500 s.p.h.
Max. stamping speed: 4000 s.p.h.
Foil pull, rewind: Longitudinal 3
Sector of heating: 6
Max. foil advance: 700 mm
Max. foil diameter: 180 mm
Foil core diameter: 25(1’’),76(3’’) mm
Min. Foil width: 45 mm
Heating capacity: 21 kW
Total capacity: 51 kW
Total weight: 18 T
Dimensions: 6000X4125X2140 mm
